● Precise Restoration ● Compliance-Enabled Empowerment
Unice Circuit's PCB Reverse Engineering Service is a technical service that relies on a professional technical team and advanced equipment to conduct systematic analysis of existing circuit boards (physical boards, assembled boards, or incomplete drawings), accurately restoring design documents (schematic diagrams, PCB layout diagrams, Gerber files) and bill of materials (BOM). We are committed to solving customers' pain points
such as "no drawings for old equipment maintenance", "lack of original data for design upgrades", and "need for reference basis for technical research", while strictly adhering to intellectual property laws and regulations to ensure the entire service process is legal and compliant.
We have established a "four-step closed-loop" technical process, ensuring the accuracy and usability of
reverse engineering results through refined operations and multi-dimensional verification,
with errors controlled within the industry-leading range of ±0.02mm.
Our service is widely applicable to multiple fields such as industry, medical care, consumer electronics,
and scientific research, providing customized solutions for different customers:
The core objective is to enhance product competitiveness. Based on the restored design files of an existing product or a competitor's product, performance upgrades, functional expansions, and cost optimizations (e.g., reducing power consumption, minimizing footprint, improving stability) can be implemented. This addresses the evolving needs of sectors like consumer electronics and new energy.
The core objective is to enable innovative R&D. For university research teams or corporate R&D departments, these services can reverse engineer classic or typical circuit designs. By deconstructing and analyzing key technologies (e.g., topology, signal integrity), they provide valuable technical references and principle explanations, thereby inspiring new ideas for product development.
The core engineer team all have more than 8 years of experience in PCB design and reverse engineering, combined with high-precision scanning and testing equipment, ensuring the consistency between the restored files and the original board reaches over 99.9%.
Sign the "Intellectual Property Compliance Agreement" with customers before the service to clarify the customer's legal right to use the original circuit board; refuse to undertake any projects involving patent infringement or trade secrets, and regularly conduct employee intellectual property law training to avoid legal risks in the process.
Regular single/double-layer boards are completed in 3-5 working days, 4-8 layer multi-layer boards in 5-7 working days, and 24-hour expedited processing is supported for urgent projects, greatly shortening the customer's waiting cycle.
Provide one-stop connection services from file restoration to sample production and mass production, and offer free technical consultation within 30 days after delivery to assist customers in solving problems encountered in the use of files.
Unice Circuit always adheres to "technology as the foundation and compliance as the principle" to provide customers with reliable PCB reverse engineering services, helping you efficiently solve technical problems
and promote product innovation and iteration under the premise of legality and compliance.
✅ Superior Reliability ✅ Extreme Precision ✅ Maximum Efficiency
Accelerate Your Product Leadership
Important Compliance Notice: When customers entrust PCB reverse engineering, they must ensure that they have legal ownership or right to use the provided circuit board and have not infringed on the intellectual property rights of third parties. Unice Circuit only provides technical services and does not bear legal liability caused by non-compliant subject matter provided by customers.
